| Battery Type | Compact storage batteries, Alkali and lead-acid batteries |
| Battery Capacity | 0~1200安培小時 |
| Measurement Condition | 電流：約40mA，4mA，400µA，40µA，4µA 頻率：1KHz |
| Resistance | 4mΩ，40mΩ，400mΩ，4Ω，40Ω，400Ω | ±3% | 1µΩ |
| DC Voltage | 6V，60V | ±0.1% | 1mV |
| Temperature | -20~60℃ | ±1℃/±1.8℉ | 0.1℃/0.1℉ |
| DC Current Range | 600A | ±2% | 0.1A |
| Open Circuit Voltage | Max. 5V |
| Data Memory and Read | 999筆 |
| Auto Datalogging | Micro SD 4GB（最多99個區塊） |
| Comparator | Setting: resistance upper and lower limits and voltage threshold limit. Memory: 99 sets of values |
| Operating Environment | 溫度0~40℃，濕度80%RH以下 |
| Maximum Input Voltage | 60VDC |
| Power Supply | six AA size 1.5V alkaline batteries or AC adapter |
| Battery Life | 5.5小時 |
| Dimension | 198 × 94 × 49 mm |
| Weight | 530 g |
| Accessories | 夾式測試線含溫度感應器、探針式測試線、3092P直流電流轉換器、歸零調整板、說明書、電池、電源轉換器、USB纜線、軟體光碟、攜帶盒 |
