Digital Multimeter FLUKE-179

SKU: FLUKE-179 Category: Tags: ,
  • Brand:FLUKE
  • True-RMS AC current and voltage measurements
  • Frequency, capacitance, resistance, continuity and diode measurements
  • Backlit digital display, analog bar graph, and built-in temperature measurements with included thermocouple
  • Manual and automatic ranging
  • Display Hold and Auto Hold
  • Min/Max-Average recording

Specification

ModelFLUKE-179AccuracyResolution
DC Voltage Range600mV/6V/60V/600V/1000V±0.09%0.1mV
AC Voltage Range600mV/6V/60V/600V/1000V±1%0.1mV
DC Current Range60mA/600mA/6A/10A±1%0.01mA
AC Current Range60mA/600mA/6A/10A±1.5%0.01mA
Resistance Range600Ω/6KΩ/60KΩ/600KΩ/6MΩ/50MΩ±0.9%0.1Ω
Capacitance1µF/10µF/100µF/9999µF±1.2%1nF
Frequency100Hz/1KHz/10KHz/50KHz±0.1%0.01Hz
Temperature-40℃~400℃/-40℉~752℉±1%0.1℃/0.1℉
Diode2.4V±1%0.001V
導通性蜂鳴器在<25Ω時會發出聲響,>250Ω時會關閉
Display Digital6,000 counts
Battery Life鹼性,典型值200小時(無背光)
Operating Environment溫度0℃~40℃,相對濕度0%~70%RH
Storage Temperature-30℃~60℃
Overvoltage CategoryEN 61010-1至1000V CAT III,EN 61010-1至600V CAT IV
Agency ApprovalsUL,CSA,TÜV
Dimension185 × 90 × 43 mm
Weight420g
